Sell concrete truck mixer - [ Sell Product ]

Place of Origin : Shenyang,China
Post Date : 14-02-2012
Expiry Date : 02-03-2013

Trade Description

Main Specification For HOWO Truck Mixer
Model HNJ5253GJBA
Mixing
Drum
Technical
Data Volume Of Drum 15m3
Effective Mixing Volume 9m3
Max.diameter Of Drum Φ2360 Mm
Incline Angle 14
Rotate Speed 0-14r/min
Dischange Capacity Slump=5cm About 30S/m3
Slump=8-21cm About 20S/m3
Water Supply System Water Supply Style Mini-electric Pump Or Pressure Water Tank
Tank Volume 380L
Chassis
Technical Data Chassis Brand HOWO
Chassis Model ZZ1257N3847C
Wheelbase 3625+1350mm
Tread (forward/backward) 2022/1830mm
Max. Speed 75km/h
Min. Swerve Diameter ≤18m
Min. Distance To Ground 360mm
Engine Engine Model WD615.95
Max. Power 247kw
Max. Torque 1350N M
Environment Standard EUR III

Dimension L×W×H 9220×2496×3880
