HDMI Extender up to 197ft/HDMI Over IP - Product

Brand : MUXBOXS
Model : MB-HD60
Color : Black

Size or Volume : 220mm*110mm*85mm
Other Specification : Name HDMI Extender Via One Cat5e/6 Cable Function Transmission Signal 1080P HDMI Signal Transmission Channel One Channel Transmission Cable One Cat5e/6 Cable Transmission Distance(max) 1920x1080/60fs 197ft(60m) 480i 328ft(100m) Power Power Supply Mode Power Adapter Power Input 5V DC Consumption <1.2W Property And Connector Support HDMI Version HDMI1.2 Resolution 1080p ,1080i,720p,576p,576i,480p,480i. Support HDMI Format HDMI1.3 Support EDID,CEC Yes Support VESA DDC Yes Support HPD Yes Support Audio Format DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Max Transmission Rate 10.2Gbps Audio Transmission Format Analog Stereo Audio Input/output TMDS Signal 0.5～1.5Vp-p（TMDS） Input/output DDC Signal 5Vp-p（TTL） Input Cable Length ≤6m（AWG26 HDMI1.3） Output Cable Length ≤6m（AWG26 HDMI1.3） Protection Level Surge Protection(UTP Cable ) 2KV(Different Mode) 4KV(Common Mode)per:IEC61000-4-5 ESD 1a Contact Discharge Level 3 1b Air Discharge Level 3 Per：IEC61000-4-2 Operation Environment Operation Temperature 0～55℃ Storage Temperature -20℃～70℃ Humidity(non-condensing) 0～95% Physical Properties Dimension Dimensions:110 X 80 X 30mm Shell Aluminum Color Black N.W. Transmitter：174g， Receiver：180g Stability (MTBF) >20000hrs
