500W Grid connected Pure sine wave Inverter - Product

^{MINIMUM QUANTITY¹}

^{WARRANTY^{1 YEAR}}

Place of Origin : Shenzhen,China
Delivery Time : 7
Product Capacity : 10000
Payment Terms : T/T(Bank Transfer),Western Union,PayPal

Product Description

Easy operation:connect your solar panel(DC10.5V to DC28V ) to this grid tie inverter and plug the AC power to your home power socket.If your power system need the Wide Input Voltage,try to reference our Low frequency series.

In order to achieve higher power use requirements, the use of this product can be stacked, such as: 4 grid inverter 1KW of stack used is equal to 4KW

Physical Specification

Other Specification : Feature: - Generates Pure Sine Wave - Automatic Power Adjustment - Constant Power Output - Low Distortion Output On All Ranges - Allow Different Power Factor From Loads - Compact And Light Weight Design - Maximum Power Point Tracking (MPPT) - Optimize Power Output - Plug And Play Design, Simply Plug Into An Outlet (GFI), No Hard-wiring - Stackable (connect In Parallel For Higher Output) - Aluminum Enclosure Will Act As Heat Sink To Help Dissipate Heat - Simple And Safe Installation - Island Protection: Inverter Will Shut Down During Black Outs. - Grid-Tied - Sell Green Power Directly Back To The Grid At A Premium Rate (depends On Your Location) Electrical Specifications-output Mode YTP-500 AC Output Power 500W Maximum AC Output Power 90~140V 190~260V Frequency 45Hz53Hz/55Hz~63Hz Total Harmonic Distortion (THD) <5% Power Factor 0.93~0.99 Island Protection Yes, Inverter Shuts Down During Black Out Output Current Waveform Pure Sine Wave Electrical Specifications - Input: DC Input Voltage (Solar & Wind) 10.5V~28V Peak Inverter Efficiency 86~94% Over-current Protection 70A Reverse Polarity Protection Fuse Power Consumption (Standby) <1W Stackable Unlimited As Long As It Doesn't Exceed Main Circuit Amperage Limit Mechanical Specifications: Operating Temperature Range -20℃ - 65℃ Weight 2.1KG 3.00KG Packing Dimension (L X W X H) 350 X 255 X155mm Mounting Wall Mount At Base AC Cable Length 1.8m Cooling Convection Cooled With Fan Display 1 Red And 1 Green LED
