SU-3280 - Product

Place of Origin : Taipei,Taiwan, Province Of China

Product Description

If you are looking for high speed gang programmer, we strongly recommend our new product SU-320 and SU-3280 series. Both of them are stand-along universal programmer.

We provide at least 2 to 16 site, depends on your request.
---If you need any further information please contact us---

Physical Specification

Other Specification :  +INTRODUCTION+ SU-3280 Is High Speed Programming For Design Engineering And Small Production. It Supports PC-based And Stand-along Programming Mode Which Through LCD And Keypad Download The File To The Inside 3.2GB Memory. Moreover, SU-3280 Adopts Modular Design. If With The Universal DIP Module, You Can Just Use General Type Adapter On The Market For Different Package. Or You Can Select Gang Module For 8-16 Site Programming. +EXAMPLE+ As You Can See SU-3280 Is Gang 16 Site Programming (Please See The Photo) There Are 4 Module Adaptors On SU-3280. And Each Of Module Adaptors Has 4 Sockets (for NAND, NOR Or SPI.etc.) However, If You Don`t Need So Many Programming, We Advise You To Use SU-320 Which Has 1 Adaptor And 4 Sockets. Also, The Speed And Quantity Is The Fastest. For Example, We Test The Duration W25Q32BVSS (4 Pcs) On SU-3280 The Total Average Of The Speeds Is 29.8 Sec (include Erase+ Blank Check+ Program+ Verity) +Support Device+ NAND, NOR FLASH, SPI EPROM, EEPROM, MPU, MCU, CPLD, NV-RAM. +Specification+ Power Signal: ● Logic Signal Level : 1.5V~6.0V,10mV ● IOL,IOH Current : 10mA ● Logic Signal Frequency : 75MHz (3-5V) / 60MHz (2.5V) / 45MHz (1.8V) / 25MHz (1.5V) ● Signal Skew : <±2.5nS (3-5V) ● Clock : 0Hz~75MHz ● VDD & VIO Level : 1.5V~6.5V,10mV ● IDD & IIO Current : 400mA ● Display: 20X4 Character LCD / WORK & PASS LED ● Button : Direction Key X 4. START Key With Light X 1 ● Embedded Memory : 2GBytes FLASH ● Module Dimension : 120mm(L) × 75mm(W) ● SU-320 Dimension : 360mm(L) × 190mm(W) × 64mm(H) +PC System Requirement+ ● Operating System: Windows 8 / 7 / Vista / XP ( 32bits & 64bits ) ● Processor: Pentium 4 Above ● Memory: 2 GB RAM Above ● Hard Disk: Main Program 500MB Above / Buffer 2GB Above ● Communication: USB 2.0 High Speed
