16340 battery - [ Sell Product ]

Place of Origin : Shenzhen,China
Post Date : 07-11-2022
Expiry Date : 23-12-2037

Trade Description

Main Technical Parameter Of The ELB 700mAh 16340 Battery:

ELECTRICAL SPECIFICATION:
Standard Voltage:3.7V
Nominal Capacity:700mAh
Stored Energy:2.24Wh
Resistance:60 MO
Self Discharge Rate:<3% Per Month
Maximum Continous Charge Current:700mA
Maximum Continous Discharge Current:700mA
Charge Cut-off Voltage:4.2V
Discharge Cut-off Voltage:2.75V
Cycle Life(25°C):>1000 Times@80%DOD

MECHANICAL SPECIFICATIONS:
Dimensions (mm):D16×H34
Weight: 20g
Terminal Type:Flat
Case Material:Alloy
Enclosure Protection:/

TEMPERATURE SPECIFICATIONS
Discharge Temperature:0 To 45°C
Charge Temperature:-20 To 55 °C
Storage Temperature:-20 To 60 °C

The Main Features Of ELB ELB 900mAh 18350 Batteries 16340 Battery :

Proven Operating Wide Temperature: -20~60 °C

Standard 18350 Size.

Support 1C Continuous Discharge.

1000tims Cycle Life@80%DOD.

High Quality NCM Chemistry, Which Have Light Weight And Large Energy Density.

For More Information, Please Visit Https://www.ecolithiumbattery.com/
