Place of Origin : Shanghai,China
Post Date : 25-05-2020
Expiry Date : 03-03-2027

General Description Of Prepainted Galvanized Steel Coil
Pre-coated Coil Is A Product Obtained By Chemical Surface Treatment (coating) Of Hot-dipped Galvanized Steel, Galvanized Steel Or Aluminum, Followed By Baking And Curing.

The Total Thickness Of The Pre Galvanized Steel Coil Consists Of The Thickness Of The Base Steel -- Coating -- Primer -- Topcoat -- Protective Coating. The Top Coating Is 10-25 Microns Thick And The Back Coating Is 5-20 Microns Thick. The Thinner The Basic Steel Thickness, The Higher The Price Of PPGI Steel Coil, Because The Processing Cost Will Be Higher.
Usually, The Paint Material Is Polyester (PE) And The Back Paint Color Is White And Gray. Colors Can Be Customized According To RAL Color CARDS Or Customer Samples. Can Make Special Patterns, Such As Wood Grain, Flower Pattern, Camouflage, Brick.
PPGI Steel Coil Specification
Product Name Prepainted Galvanized Steel Coil
Material CGCC, DX51D,Q195,Q235
Zinc 20-120g
Thickness 0.13-0.8 Mm
Width 600-1250 Mm
Color All RAL Color , As Client’s Request
Paint Top Paint : 10-30mic Back Paint: 5-25 Mic
Paints PE, SMP, HDP, PVDF
T Bend < 3T
Pencil Hardness >2H
Coil ID 508/610mm
Coil Weight 3-8tons
Surface Glossy And Matt
Glossy 30%-90%
Package Standard Export Package (Detailed Picture Is As Follows)
Hardness Soft (normal), Hard, Full Hard(G300-G550)
HS Code 721070
Country Of Origin China
Business Type Supplier And Manufacturer
Brand Name Huaro
Application Of Prepainted Galvanized Steel Coil
Uncoiling Machine Uncoiling, Leveling, Length Fixing, The Painted Galvanized Steel Coil Is Cut Into The Desired Length And Width Of Flat PPGI Plate, And The Roll Forming Machine Is Used To Process Various Styles Of PPGI&PPGL Roof Board, Such As Corrugated Steel Plate, Wave Tile, Roman Longtile Profile.
