Place of Origin : Shenzhen,China
Post Date : 03-03-2011
Expiry Date : 03-04-2011

Brief Introduction
1.No. Of Contact:4,7,10,19,32,50
2.Locking Way Is Threaded Locking
3.Anti-misoperation By Key And Keyway
4.With Three Kinds Of Back Shell:straight Sealing,short Cable And Long Cable Clamp
5.There Are Metal Dust-proof Lid On Plug And Receptacle,There Is Sealing Mounting Rubber Pad For Receptacle

Specification
1.Operating Temperature Range:-65℃--+125℃
2.Relative Humidity:95% When The Termparature Is 40℃
3.Contact Resistance:≤10mΩ
4.Insulation Resistance:≥1000mΩ
5.Dielectric Strength: 1000V
6.Sine Vibration:10Hz--2000Hz,196m/s²
7.Shock:980m/s²
8.Sealing Function:(just For Sealing Receptacle)0.2MPa Pressure Difference In 1 Min, Water Testing Wihout Bleb)
9.Durability:300 Times
