This is the product title

UHF Band 440~470MHz RF Drop In Circulator 0.3dB 300W - Product

UNIT PRICE

40
MINIMUM QUANTITY

1
WARRANTY

1 YEAR

Place of Origin : Shenzhen,China
Delivery Terms : EXW
Delivery Time : 7days
Product Capacity : 1000pcs/month
Payment Terms : T/T

Product Description

Model Number: UIYDC3538A440T470
Frequency Range:440~470MHz
Bandwidth:40%
Insertion loss:0.3dB
Isolation:23dB
VSWR:1.2
Forward Power:300W
Reverse Power:300W
Connector Type: TAB
Temperature: -30~+70?
Dimension:35*38*11mm

Basic Information

Brand : UIY
Model : UIYDC3538A440T470
Material : Ferrite
Color : Gold
Expiry/Validation Period : 60days

Physical Specification

Size or Volume : 35*38*11mm
Weight : 90g
Other Specification :

Model Number: UIYDC3538A440T470

Frequency Range:440~470MHz

Bandwidth:40%

Insertion Loss:0.3dB

Isolation:23dB

VSWR:1.2

Forward Power:300W

Reverse Power:300W

Connector Type: TAB

Temperature: -30~+70?

Dimension:35*38*11mm
