Fiber Optic ODF/Patch Panel - Product

Brand : KTX
Model : 1U-Rack
Material : SPCC Or AL
Color : RAL 9011 Or RAL 7035
Expiry/Validation Period : 1000

Size or Volume : 483(L)*220(W)*44(H)mm
Weight : 3.2-3.8kg
Other Specification : Description: Fiber Optic Patch Panel Is An Integrated Unit For Optical Fiber Management, And Be Used As Distribution Box, Which Can Fix And Manage The Fiber Optic Cables Inside The Box As Well As Provide Protection. This Series Of Equipments Can Be Flexible Configuration, Simple Installation, Convenient To Maintenance, Easy To Manage. Features: (1)Fiber Optic ODF Unit/Patch Panel, Drawer Style For Ribbon Cables, Common Cables And Pigtails; (2)Slidable Rack-mounted ODF Box Is With The Drawer For Splicing, Easy To Withdraw The Fibers When Testing And Distributing; (3)Reliable Fastening, Stripping And Earthling Devices For Optical Fiber, Its Special Structure Is Convenient For Operation And Protection; (4)Suitable For SC, FC, ST, LC Adapter, And Duplex Or Simplex Is Available; (5)19-inch Rack Standard Size With High Capacity, The Box Is Electrostatic Spraying And Looks Beautiful; Specification: (1)Size (L*W*H):483*220*44(mm) (2)Material Is Optional For: SPCC Or AL (3)Color: RAL 9011 Or RAL 7035 (4)Insulated Resistance: >=2×10Mohm/500VDC (5)Humidity: =<85%(+30centigrade) (6)Atmosphere Pressure: 70KPa~106KPa (7)All Material Is ROHS Compliant (8)Compliant With ISO9001:2000 Certification Applications: (1)Telecommunication System (2)Fiber To The Home (FTTH) (3)LAN/ WAN (4)CATV
