36pcs IR Camera - Product

^{MINIMUM QUANTITY^1PCS}

Place of Origin : Shenzhen,China
Payment Terms : TT

Product Description

• mage sensor: 1/3-inch Sony color CCD
• Horizontal resolution: 420TVL
• Signnal system: PAL/NTSC
• Picture pixels: PAL: 500 (H) x 582 (V), NTSC: 510 (H) x 492 (V)
• LED No.: 36 pieces Ø5 LEDs
• Ranging distance: 30 to 35m
• Infrared wavelength: 850nm

Basic Information

Brand : GRT
Model : GI36B
Material : Metal

Physical Specification

Other Specification : � Mage Sensor: 1/3-inch Sony Color CCD � Horizontal Resolution: 420TVL � Signnal System: PAL/NTSC � Picture Pixels: PAL: 500 (H) X 582 (V), NTSC: 510 (H) X 492 (V) � LED No.: 36 Pieces Ø5 LEDs � Ranging Distance: 30 To 35m � Infrared Wavelength: 850nm � Sync. System: Internal Synchronization � S/N Ratio: >48dB � Lens: 6mm/8mm/12mm IR Varifocal Lens � PAL: 1/50 To 1/1,00,000 Seconds � NTSC: 1/60 To 1/1,00,000 Seconds � Gamma Collection: R = 0.45 � Gain Control: Auto � White Balance: Auto � Backlight Compensation: Auto � Minimum Illumination: 0 Lux (IR ON) � Video Output: 1.0Vp-p, 75Ω � Power Supply: 12V DC ±20 % � Operating Temperature: -10 To +50°C � With Anti-reflection Glass � With Cable-managed Bracket � Use IR Crystal Filter To Reduce The Noise Of Camera At Night � Model: GI36B
