Longitudinal Seam Submerged Arc Welding Pipe - Product
Place of Origin : Hunan,China
Delivery Terms : FOB, CIF, CFR, EXW
Delivery Time : 30days
Product Capacity : 300000ton/month
Payment Terms : T/T, L/C, Paypal
Product Description
Usage: Used for low pressure liquid delivery, such as water, gas, and oil.
Process:
LSAW (Longitudinal Submerge-arc Welded) UO(UOE)、RB(RBE)、JCO(JCOE)
DSAW (Double Submerged arc welded)
Size:
Outer Diameter: 219mm-1820mm
Wall Thickness: 5.0mm-50mm
Length: 6mtr-18mtr
End:square ends (straight cut, saw cut, and torch cut). or beveled for welding, beveled,
Surface: Lightly oiled, Hot dip galvanized, Electro galvanized, Black, Bare, Varnish coating/Anti rust oil, Protective Coating.
Basic Information
Brand : Great Pipe
Physical Specification
Other Specification : Steel Grade:
BS:1387, EN10217:S185, S235,S235JR, S235 G2H, S275, S275JR, S355JRH, S355J2H, St12, St13, St14, St33, St37, St44, ST52
ASTM A 53: Gr. A, Gr B, Gr C, Gr.D
API 5L: A, B, X42, X46, X52, X56, X60, X65 X70
GB/T9711: L175, L210, L245, L290, L320, L360, L290, L320, L360, L390, L415, L450, L485, L555
GB/T3091, SY/T5037, SY/T 5040,CJ/T 3022:Q195, Q215, Q235, Q275, Q295, Q345, 08F, 08, 08AL, 08F, 10F, 10, HG5, DF08 SPHC, M8
Packing:Plastic Plugs In Both Ends, Hexagonal Bundles Of Max. 2,000kg With Several Steel Strips, Two Tags On Each Bundle, Wrapped In Waterproof Paper, PVC Sleeve, And Sackcloth With Several Steel Strips, Plastic Caps.
Test:Chemical Component Analysis, Mechanical Properties (Ultimate Tensile Strength, Yield
Strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.
Mill Test Certificate:EN 10204/3.1B
Third Party Inspection:SGS, BV, Lloyds Etc.
