PP/PE food woven sack making machine - Product

^{MINIMUM QUANTITY^{1 SET}}

^{WARRANTY^N/A}

Place of Origin : Wenzhou,China
Delivery Terms : FOB,CIF
Delivery Time : Within 45-60 Days
Product Capacity : 30-80kg/h
Payment Terms : T/T,L/C

Product Description

PP/PE food woven sack making machine
This machine uses the Polypropylene(PP) or high density polyethylene(HDPE) material to produce tapes for PPwoven bags,weaving through production procedures of material heating & extruding,splitting the film into tapes.stretching & forming tapes,and then winding on the bobbins by winding machine,finally put the bobbins with tapes on circular loom for weaving.
The tape extruding & stretching machines are our,With the use of special and advanced technology,we

Basic Information

Brand : Tianchen
Model : SJ-FS5.5-110 IIB/600
Material : PP
Color : White And Green
Expiry/Validation Period : N/A

Physical Specification

Size or Volume : 23600*2500*1800mm
Weight : 8000kg
Other Specification : Model SJ-FS5.5-110 IIB/600 Diaeter Of Screw 110mm L/D Ratio Of Screw 20﹕1 Revolution Of Screw 10-55r/min Motor Power Of Extruder 18.5kw Heating Power Of Extruder 24kw Width Of Die-lip 600mm Diameter Of Drum 320mm Number Of Arch Heating Plate 2pcs Heating Power Of The Plate 15kw Stretching Ration 4-7 Production Capacity 30-80kg/h Winding Speed 20-150m/min Number Of Winder 100spindles System Installed Capacity 98kw Normal Operational Capacity 64kw Weight 8000kg Overall Dimension(J*W*H) 23600*2500*1800mm
