Pressure Transmitters - Product

^{MINIMUM QUANTITY^1PCS}

^{WARRANTY^{2 YEARS}}

Place of Origin : Shenzhen,China
Delivery Terms : Exw，Fob CIF
Delivery Time : 3-4 Working Days
Product Capacity : 500pcs/day
Payment Terms : T/T Paypal

Product Description

PROFESSIONAL PRESSURE ,LEVEL,TEMPERATURE TRANSMITTER SOLUTION PROVIDER
Instruction:
HPT-6 pressure transducers are based on piezoresistive silicon pressure sensor packaged in 316L stainlesssteel housing. The sensing package utilizes silicone oil to transfer pressure from the 316L stainless steel diaphragm to
the sensing element.
Through strict component making, semi-finished product and all-finished product testing and aging,the transmitter is stable and reliable, having excellent flexibility

Basic Information

Brand : HT
Model : HPT
Material : Stainless Steel
Color : Silver
Expiry/Validation Period : 1

Physical Specification

Other Specification : Eature: 3 1/2 LED/LCD Display; Compact Outline, Easy Installation; Strong Compatibility; Adjustable Pressure Unit. Applications: The Oil Industry, Chemical Industry,Electric Power. Hydraulic Pressure System,Pneumatic System Energy And Water Treatment System. Automation Equipment Industrial Process Control Performance Parameters Pressure Range: -0.1~250MPa Pressure Type: Gauge Pressure,Absolute Pressure Output Signal: 4~20mA , 0~10V Or Optional Display Mode: 3 1/2 LED Or LCD Display Accuracy(%FS): 0.1 0.25 0.5 Nonlinearity(%FS): <0.1 <0.25 <0.5 Hysteresis(%FS): <0.1 <0.25 <0.5 Repeatability(%FS): <0.1 <0.25 <0.5 Zero Drift(%FS/): <0.02 Full Scale Drift (%FS): <0.02 Stability (%FS/Year): <0.25 Operating Voltage(V): 12~36V DC(Standard:24V) Operating Temperature : -20~85 Overload Capacity(%): 300 Damping : Adjustable Life Span: More Than 9 Million Times Pressure Cycle Load Resistance: 750 Response Time(ms): 1 Media: Media Compatible With 316L Disphragm Material: 316L Or The Ceramic Diaphragm Housing Material: 1Cr18Ni9Ti Pressure Interface: M20*1.5,G1/2,G1/4,1/4NPT Or Others Enclosure Rating: IP65 Weight: 280g
