Place of Origin :
Built for demanding environments, HOZO industrial washer extractors excel in high-volume laundry processing. These robust systems deliver superior sanitization for hospitals, premium hotels, and commercial laundry facilities, meeting the most rigorous industry standards.
| Technical Data | |||
| Model | HG-30 | HG-50 | HG-100 |
| Capacity | 30kg | 50kg | 100kg |
| Inner Drum Dimension | |||
| Diameter | 942 | 1160 | 1450 |
| Depth | 930 | 1000 | 1250 |
| Rotating Cage Capacity | 650 L | 1056 L | 2064 L |
| Inner Drum Speed | |||
| Cage Speed | 34 | 32 | 28 |
| Rotating Cage Rotation Mode | Bidirectional Rotation | ||
| Electrical Connection | |||
| Voltage System | 3-Phase AC 380V 50Hz | 3-Phase AC 380V 50Hz | 3-Phase AC 380V 50Hz |
| Main Motor Power | 0.75kw 6P | 1.1kw 6P | 2.2kw 6P |
| Fan Power | 0.75kw 4P | 1.5kw 4P | 1.5kw 4P X2pieces |
| Total Machine Input | 1.5kw | 2.6kw | 5.2kw |
| Electrical Heating | 28kw | 44kw | 60kw |
| Conductor Section - Steam Heating - Gas Heating - Electric Heating |
4x2.5mm² 4x2.5mm² 3x10mm² +1x6mm² |
4x2.5mm² 4x2.5mm² 3x16mm² +1x10mm² |
3x4mm² +1x2.5mm² 3x4mm² +1x2.5mm² 3x25mm² +1x16mm² |
| The Supply Voltage Can Be Customized As Required | |||
| Steam Connection | |||
| Steam Inlet | DN 25 (1”) | DN 25 (1”) | DN 25 (1”) |
| Steam Pressure | 0.4-0.6Mpa | 0.4-0.6 Mpa | 0.4-0.6 Mpa |
| Steam Consumption | 40-60kg/h | 60-80kg/h | 90-120kg/h |
| Air Connection(LPG/NPG) | |||
| Gas Inlet | DN20 (3/4”) | DN20 (3/4”) | DN40 (1.5”) |
| Gas Pressure | 0.05-0.08 MPa | 0.05-0.08 MPa | 0.05-0.08 MPa |
| Gas Consumption | 2.5m³/h | 3.5m³/h | 6m³/h |
| Drain Connection | |||
| Exhaust Outlet | Ø240 | Ø240 | 310x310 |
| Exhaust Air Rate | 2400m³/h | 3000m³/h | 6000m³/h |
| Machine Dimensions | |||
| WidthxDepthxHeight | 1120x1580x1750 | 1340x1640x2080 | 1630x2020x2440 |
| Weight | 420 | 700 | 1300 |
