Hydraulic puzzle parking system 5 Levels - Product
MINIMUM QUANTITY
1 SYSTEM
Place of Origin : Weifang, Shandong,China
Delivery Terms : Advance Payment
Delivery Time : 60
Product Capacity : 10000000
Payment Terms : TT
Product Description
Work Principle
This system is designed with 5 layers and multi-columns layout. Each layer is designed with a spare space as an exchanging space. All spaces can be auto-lifting freely except the spaces in the first layer and all the spaces can be auto-transverse moving except the spaces in the top layer. When a space needs to park or release a car, all spaces under the space will make a one space transverse moving to the empty space and forms a lifting channel under this space. In this case,
Basic Information
Brand : Dayang
Model : PSH5
Material : Galvanized Steel Frame
Color : SILVER
Expiry/Validation Period : 60
Physical Specification
Size or Volume : 2600
Weight : 1200
Other Specification : Mode Of Drive
Hydraulic
Size Of Car (LÃâ€â€WÃâ€â€H)
5000mmÃâ€â€1850mmÃâ€â€1550mm
Weight Of Car
2000kg
Lifting Motor Power
11kw
Lifting Speed
18-25m/min
Sliding Motor Power
0.2kw
Sliding Speed
7.5m/min
Electricity
AC380V,50Hz, 3 Phases 5 Wires System
Safeguard Devices
Hydraulic Whole Protection And Anti-fall Frame
Anti-fall Frame (our Patent)
Warning Devices
Sound, Light, Electricity
Malfunction Indication
Fault Diagnosis By Computer, Liquid Crystal Display
Frame Composition
Columns And Beams Are Made Of H Type Steel, Channel Steel, Angle Steel And Square Pipes;
Parts Appearance Treatment
Galvanized Treatment And High-grade Anti-corrosion Paint
Modes Of Operation
LCD/ IC Card/Manual
Controller
PLC
Way Of Parking In And Out
Forwarding, Reversing Into The Space
