LDW Digital Display Electromechanical Universal Testing Machine - Product

Brand : PTE
Model : LDW
Color : Blue

Weight : 180kg
Other Specification : LDW Series Digital Display Electromechanical Universal Testing Machine Application: This Kind Of Machine Is Widely Used In Metallurgy, Machinery, Building Engineering And Materials, Automobile, And Shipping Industry, College, University And Quality Assessment Department, Which Can Test The Mechanical Performance Of Metal, Plastic, Rubber, Spring, All Kinds Of Rope Materials And Other Materials. It Can Meet Global Standards, Such As ASTM, DIN, BS, JIS, GB, Etc. It Use LCD Controller To Control Machine. LDW-S Series Main Specifications: Model LDW-300 LDW-200 LDW-100 LDW-50 LDW-20 LDW-10 Max. Load 300KN 200KN 100KN 50KN 20KN 10KN Load Accuracy ≤±1% Load Range 2%-100% Of Full Scale Test Speed 0.1-250mm/min 0.1-500mm/min 0.1-500mm/min Speed Accuracy ≤±1% Disp. Resolution 0.01mm Effective Test Width 570mm 400mm 400mm Effective Tensile Space 600mm 600mm Effective Comp. Space 700mm 700mm Dimension 1130×650×2650mm 830×550×2000mm 760×500×1750mm Power Supply 380V, 3ph, 4/3KW 220V, 1ph, 1.5KW 220V, 1ph, 1KW Weight 1800KG 720KG 460KG Grips Wedge Type, Plate Type And Other Grips As Consumer’s Demand Load Frame Type Gate Type Features: 1. High Accuracy Servo Motor To Control Test Speed. 2. Ball Screw No Backlash To Guarantee The Low Noise And High Driving Efficiency 3. High Accuracy Load Cell To Measure The Test Load 4. High Accuracy Photoelectric Encoder To Measure The Displacement. 5. LCD Controller Has Strong Function, It Can Show Test Load, Displacement, Test Speed, Test Status, And Also Has The Function Of Peak Load Holding, Peak Displacement Holding And Self Return Original Position. 6. Thousands Of Test Fixture Can Be Used According To Different Test Request; 7. Compact Structure With Easy Operation. 8. Limit Switch And Setting In The Controller To Guarantee The Safety
