Vehicle SD Card GPS Digital Tachograph With Internal Printer - Product

Other Specification : Vehicle SD Card GPS Digital Tachograph With Internal Printer Integrate GPS Tracking/monitoring, Display Screen, Printer, Driving Recorder, SD Card Video Recorder, IC Card Reader, USB Interface, Multi-routes Data Serial Port, Build-in Microphone And Speaker, All The Module Is Thinkable Can Be Integrated. Vehicle Standard Installation Structure Design And Integration Structure, It Is Easy To Install. Meet The Requirements Of National Standard GB-T19056-2003/Guangdong DB44/T578. - - - - Technical Specifications | | Working Voltage | 933 V/DC | Limiting Voltage | 100V/DC | Car Battery Protecting Voltage | Low: 9V (12V Car Battery)or 20V (24V Car Battery)high: 36V | Power Voltage Of Anti-reversed Connection | 100V | Average Working Current | 90mA DC 12V | Power Saving Mode | 20mA DC 12V | Backup Battery | Working Time 1h | Dimension | 140x 180x 60mm(L X W X H) | Canning Material | Panel: Industry Plastic, Case: Electrolysis Steel Plate | Main Device Weight | 1.52kgnet Weight | Interface | | GPS Antenna | SMA Interface: 26dB | GSM Antenna | SMA Interface: 3dB | Vehicle Detecting Interface | 11 Routes Signal Input | Analog Quantity Interface | 2 Routes Analog Signal Input | Output Interface | 3 Routes Low Level Output | SD Card Interface | SD Memory Card | Video Interface | Serial Video Input, Can Be Expanded To 4 Video Cameras | Voice Interface | 2 Routes Voice Interface | Data Interface | 4 Routes RS-232 Serial Port, 1 Route USB Interface | IC Card | Contact-type Driver IC Card | - - - - Main Features: Based International Newest Chip, Multiple Core Structure, Powerful Modularized Function Design, Integrated Car GPS Tracking, Dispatching And Management Integration Indust
