running capacitors - Product

^{MINIMUM QUANTITY⁵⁰}

Place of Origin : Tongling,China
Delivery Terms : 5days
Delivery Time : 6days
Payment Terms : T/t ,western Union

Product Description

The capacitor takes heavy-edge metallized Al/Zn PP film as electrodes and dielectric. Its components are sealed with flame-retardant epoxy resin. It has cylindrical outline with high moisture resistance and stability.

Basic Information

Brand : Sf
Material : Metallized Film

Physical Specification

Other Specification : Applications Broadly Applied To Starting And Running Of AC Single-phase Motors At 50Hz(60Hz) Frequency For Washers And High Efficiency Compressors Of Refrigerators Etc. Technical Specifications Standard：IEC 60252-1:2001 Technical Features： Climate Type：40/70/21 Or 40/85/21 Capacitance Tolerance：Ã‚Â± 5% Insulation Resistance：≥3000S（MΩÃ‚Â·μF） Dielectric Dissipation Factor：tgδ≤0.002 (50Hz～100Hz) Application Requirements： Altitude：≤2000m Residual Voltage In Application :less Than 10% Of Rated Voltage. Allowed Maximum Voltage: Less Than 1.1 Times Of Rated Voltage Permissible Maximum Current: Less Than 1.3 Times Of Rated Current
