Industrial Panel PC - Product

^{MINIMUM QUANTITY¹}

Place of Origin : Shenzhen,China
Delivery Terms : Full Payment /1pc
Delivery Time : 7 Days/1pc
Payment Terms : T/T

Product Description

FEATURES:

 8inch TFT LED Screen
 Touch Screen
 FANLESS Design
 ATOM N450 1.66G
 Onboard 1G Memory
 2*USB 2.0
 3*RS232/1*RS422/485
 2*LAN
 CE/FCC/Rohs

Basic Information

Brand : Geshem

Physical Specification

Other Specification : Display Features Display Screen 8″ TFT LED Screen Resolution 800*600 Brightness 450 Cd/m2 Contrast Ratio 600:1 Touch Screen Resistive Touch Screen System Chipset N450 1.66G + ICH8 Memory Onboard 1G DDRII MAX 3G Watchdog Timer Software Programmable 1-256 Sec. System Reset Storage HDD:8GB CF Ethernet Chipset 2*RJ45 10/100/1000M LAN I/O Interface USB 2*USB2.0 COM 4* COM(3*RS232,1*RS422/485) LAN 2*RJ45 1000M VGA 1*VGA Environment Shock Protection IEC 60068-2-27 50 G @ Wall Mount, Half Sine, 11 Ms Vibration Protection IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.) 2 Grms @ 5 ~ 500 Hz, Reliability MTBF≥50000h; MTTR≤0.5h Operating Temperature -20℃～60℃ @ 5 ~ 85% RH. (with Air Flow) Storage Temperature -20℃ ～60℃ Humidity 95% @40℃, Non-condensing Ingress Protection Front Panel IP65(Optional) Power Power Supply 12V DC Power Input Operating System O/S Linux / Windows 7 / XP Structure Dimensions 235mm (L) *183 Mm (W) *60 Mm (H) Material FANLESS Design ,Aluminium Alloy Front Panel Color Slivery/Black/white
