Welding Rods AWS E6013 - Product

^{MINIMUM QUANTITY^1000KGS}

Place of Origin : Wuxi,China
Delivery Terms : CNF
Delivery Time : 10-15 Days
Product Capacity : 20000tons/Year
Payment Terms : T/T, L/C

Product Description

CHE40 (ASW E6013) is the general mild welding electrode with titanium oxide type coating. It is able to provide excellent welding performance and satisfactory weld can be obtained in all position welding, it is widely used in ordinary strength mild steel structures especially suitable for intermittent welding to sheet steel and small work pieces as well as cosmetic welding with smooth and shiny appearance.

Basic Information

Brand : SAFRED
Model : AWS E6013
Material : Mild Steel

Physical Specification

Other Specification : CHE40 (ASW E6013) Is The General Mild Welding Electrode With Titanium Oxide Type Coating. It Is Able To Provide Excellent Welding Performance And Satisfactory Weld Can Be Obtained In All Position Welding, It Is Widely Used In Ordinary Strength Mild Steel Structures Especially Suitable For Intermittent Welding To Sheet Steel And Small Work Pieces As Well As Cosmetic Welding With Smooth And Shiny Appearance. Chemical Composition Deposited Metal (%) C Mn Si S P Standard ≤0.12 0.25-0.60 ≤0.40 ≤0.035 ≤0.040 Typical 0.076 0.35 0.22 0.022 0.026 Mechanical Properties Of Deposited Metal Yield Point ós (Mpa) Tensile Strength ób (Mpa) Elongation δ5(%) Impact Value(J) 20°C 0°C Standard ≥305 400-560 ≥22 - ≥47 Typical 410 500 27 110 75 Sizes, Pieces & Recommended Current (AC Or DC) Size(mm) 2.5×300 3.2×350 3.2×350 4.0×400 4.0×450 5.0×400 5.0×450 Pieces(5kg) ≈303 ≈258 ≈157 ≈90 ≈80 ≈59 ≈52 Current(A) F,H 60-90 60-90 80-130 150-190 150-190 180-250 180-250 V,OH 50-80 50-80 80-110 130-170 130-170 Approvals: CCS 2 LR 2M ABS 2 GL 2 BV2 DNV 2 BKI 2 CWB E431 Packing Details: 5KG/BOX, 20KG/CARTON
