Place of Origin : Tongling,China
Post Date : 20-12-2011
Expiry Date : 31-12-2012

1.Type
Al/Zn Metallized Film
Al Metallized Film
Safety Anti-explosion Film
2.Application
Applied To Capacitors For Power System, Refrigerators And Air Conditioners
Construction
3.Aluminum/Zinc Film With Reinforced Edge
4. Specification
Item Unit Nominal Value
Roll Mm Roll Diameter Inner Diameter 76
Outer Diameter 150,300 (The Specific Diameters Can Be Customized. )
Thickness μm 4,5,6,7,8,9,10,12
Width Mm 30,35,37.5,40,45,50,55,60,65,70,75,
80,85,90,95,100,115,120,125,130,
14 ,17.5,21, 26
Margin Value Mm 2.5 , 2.0 , 1.5
