HJ－320 rotary die-cutting machine - Product

Place of Origin : Shenzhen,China

Product Description

HJ－320 rotary die-cutting machine is a new product with rotary die-cutting function.

Physical Specification

Other Specification : Introduction： HJ－320 Rotary Die-cutting Machine Is A New Product With Rotary Die-cutting Function. It Equipped With High Accurate Rotary Die-cutting System. This Machine Is Suitable For Blank Adhesive Lables. Die-cutting, Slitting Can Be Finished In One Process. It Has The Function Of Automatic Meter Counting, Automatic Stopping, Web Guiding By Photoelecric Eyes. The Machine Has The Characteristics Of Compact Structure, Fast Speed, High Efficiency, Easy Operation, Accurate Slitting, Steady Running Etc. Standard Configuration 1. One Slitting Station 2. With 1pc 3"unwinding Shaft, 2pcs 3"rewinding Shafts 3. With Meter/number Counter 4. With Two Photoelecric Eyes 5. With 8pcs Rotary Knife 6. One Magnetic Brake, Two Magnetic Clutches Product Parameters： Slitting Speed 75m/min Die-cutting Speed 70m/min Max.web Width 320mm Die-cutting Length 178mm-470mm Max. Unwinding Diameter 500mm Max. Rewinding Diameter 480mm Overall Dimensions 1.32m*1.02m*1.52m(L*W*H) Machine Weight 600kg
