Wrapped Hydraulic Rubber Hose With DIN EN856 4SH Standred - Product

Other Specification : Wrapped Hydraulic Rubber Hose With DIN EN856 4SH Standred Quick Details DIN EN 856 4SH STANDARD WORKING TEMPERATURE:-40 To +100 CONSTRUCTION: This Hose Shall Consist Of An Inner Tube Of Oil Resistant Synthetic Rubber, Four Spiral Plies Of Steel Wire Wrapped In Alternating Directions, And An Oil And Weather Resistant Synthetic Rubber Cover. APPLICATIONS: This Section Covers Hose For Use With Petroleum Base Hydraulic Fluids Within A Temperature Range Of -40+100 - - - - DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | Length | Inch | Mm | Mm | Mm | MPa | Psi | MPa | Psi | Mm | Kg/m | Metres | 19 | 3/4 | 19.0 | 28.4 | 32.0 | 42.0 | 6000 | 168.0 | 24000 | 280 | 1.61 | 20 To 40 | 25 | 1 | 25.4 | 35.2 | 38.6 | 38.0 | 5500 | 152.0 | 22000 | 340 | 2.00 | 20 To 40 | 32 | 1 1/4 | 31.8 | 41.9 | 45.8 | 32.5 | 4700 | 130.0 | 18800 | 460 | 2.64 | 20 To 40 | 38 | 1 1/2 | 38.1 | 48.8 | 53.3 | 29.0 | 4200 | 116.0 | 16800 | 560 | 3.36 | 20 To 40 | 51 | 2 | 50.8 | 63.2 | 68.1 | 25.0 | 3600 | 100.0 | 14400 | 700 | 4.98 | 20 To 40 | - - - - APPLICATIONS : Be Suitable To Carry Hydraulic Fluids, Such As Glycol, Mineral Oils, Emulsion, Hydrocarbons, Etc. WORKING TEMPERATURE: -40 To +100 We Are The Professional Manufacturer Of Hydraulic Hose And Industrial Hose In China. All Our Products Are Tested Strictly And Pass The ISO9001: 2000 And SGS Quality System Certifications. Our Below Products Have Been Exported America, Europe, The Middle East, South Africa, Mor
