NDT X Ray Pipeline Crawler - Product

^{MINIMUM QUANTITY¹}

^{WARRANTY^{12 MONTH}}

Place of Origin : Dandong,China
Delivery Terms : FOB
Delivery Time : 5 WORKING DAYS
Product Capacity : 500/YEAR
Payment Terms : TT

Product Description

Zhong Yi brand pipeline crawler is a kind of magnetic controlled pipeline robot with DC X ray unit of constant potential installed on it for check welding of pipeline.

Running in a wall or pipeline; detect internal defects and flaws through radiography technology. Pipeline Crawlers move steadily inside the pipe with speed of up to 18m/min to the distance of up to 5 kilometers and provide the efficient inspection of the pipeline.

Basic Information

Brand : Zhong Yi
Model : ZY-10C

Physical Specification

Weight : 250 KG
Other Specification : Technical Parameter/Product ZY-4C ZY-3C ZY-10C Locating System Magnetic Medium Control Available Diameter 8.6”-14” 13”-28” 20”-55” Crawler Dimension 1660×177×150mm 1500×245×200mm 1550×400×350mm Controller Dimension 198×102×150 Mm Weight 30 Kg 67 Kg 90 Kg Max. Climbing Slope 30° 30° 40 ° Turning Radius ≥10D ≥10D ≥7D Positioning Precision ±3 Mm Max. Moving Distance 5 Km (Round Trip) Creeping Speed 18 M/min Drive Mode Two Wheels Driven Two/Four Wheels Driven Four Wheels Driven X Ray Tube (Panoramic ) Model 100/160KV 160/200/250KV 200/250/300KV Max. Penetrate A3 Steel 15 Mm 30 Mm 35 Mm Exposure Time 0-5 Min Focus Size 1.0*3.5 Mm Radiation Angle 360° × 40° Anode Target Cone Target Operate Temperature -20℃~+75℃ Store Temperature -40℃~+80℃ Available Humidity ≤90% Power Supply (Lead-acid Battery) 7Ah 12Ah 17Ah
