Place of Origin : Wuxi,China
Delivery Terms : 7–30 Days Depending On Order Quantity
Delivery Time : Negotiable Based On Order Schedule
Product Capacity : 30 Tons Per Day
Payment Terms : T/T, L/C, Western Union
Induction hardened rods are high-strength steel bars with a chrome plated surface and hardened core, offering excellent wear resistance, high fatigue strength, and precision tolerance. They are widely used in hydraulic cylinders for construction machinery, agricultural equipment, mining, and industrial systems, ensuring durability and long service life under heavy-duty conditions.
| Parameter | Specification |
|---|---|
| Diameter Range | 10 Mm – 200 Mm (custom Sizes Available) |
| Length | Up To 8000 Mm (standard: 1000 Mm – 6000 Mm) |
| Material Options | CK45, ST52, 42CrMo4, 20MnV6, 40Cr |
| Surface Condition | Precision Ground And Hard Chrome Plated |
| Chrome Thickness | 20–30 μm (customizable Up To 50 μm) |
| Surface Hardness | 850–1150 HV (after Induction Hardening) |
| Core Hardness | HRC 28–35 (quenched And Tempered) |
| Surface Roughness | Ra ≤ 0.2 μm |
| Straightness | ≤ 0.2 Mm/m |
| Ovality | ≤ 50% Of ISO F7 Tolerance |
| Yield Strength | ≥ 600 MPa (depending On Steel Grade) |
| Tensile Strength | 700–900 MPa (depending On Steel Grade) |
| Salt Spray Test | 120–200 Hours (neutral Salt Spray Test, NSS) |
| Standard Compliance | DIN 2391, EN 10305, ASTM A519 |
Looking For Reliable Hydraulic Components?
Myler Hydro Specializes In chrome Plated Piston Rods, honed Tubes, And Cylinder Barrels With Proven Export Experience To The Middle East, Southeast Asia, South America, And Russia.
Get In Touch With Our Sales Team For Product Details, Technical Support, And Quotations. We Provide Fast Response, Customized Solutions, And Timely Delivery.
Email: Info@chromerods.com
Phone / WhatsApp: 86-17766334294
Web: Mylerhydro.com
Myler Hydro – Your Trusted Partner For Hydraulic Solutions.
