2 - 8mm Thickness High Quality Slitting Line - Product
Place of Origin : Meicun,China
Delivery Time : About 120 Days After Recepit Down Payment
Product Description
2 - 8mm Thickness High Quality Slitting Line
We are leading manufacturer of Coil Processing Machinery of China. We supply professional one-stop service for kinds of machines and equipments, like slitting line, cut to length line, leveling machine, etc.
We offer high quality machines and first class service to our clients, we sincerely hope our machines can make many years prosperity for our customers.
Coil basic data
1. Material: Hot/cold rolled coil, etc
2. Thickness: 2-8mm
3. Wi
Physical Specification
Other Specification : 2 - 8mm Thickness High Quality Slitting Line
We Are Leading Manufacturer Of Coil Processing Machinery Of China. We Supply Professional One-stop Service For Kinds Of Machines And Equipments, Like Slitting Line, Cut To Length Line, Leveling Machine, Etc.
We Offer High Quality Machines And First Class Service To Our Clients, We Sincerely Hope Our Machines Can Make Many Years Prosperity For Our Customers.
Coil Basic Data
1. Material: Hot/cold Rolled Coil, Etc
2. Thickness: 2-8mm
3. Width: 500-2000mm
4. Inner Diameter: 508mm, 610mm
5. Max Outer Diameter: 2000mm
6. Capacity: 20T(depends On Client's Demand)
Main Data
1. Work Speed: 0-20M/min(adjustable)
2. Slitting Width: Min 20mm
3. Slitting Width Tolerance: 0.05mm
4. Number Of Strip: Max. 10
5. Weight: About 60 Tons
6. Installation Dimension: 20M X 8M X 3M(L X W X H)
7. Standard Power Source: AC380V/50Hz
8. Paint Of The Machine: Main Body In Green, Moveable Units And Danger Area In Yellow (or According To Buyer's Demands)
Work Flow
Loading Trolley---hydraulic Decoiler---feeding Unit---sheet Head Cutter---rectification Unit---rotary Slitter---scrap Re-coiler---loop---separator & Tensioner---recoiler---unloading Trolley
