R8M Continuous Casting Machine - Product

Other Specification :  R8M Continuous Casting Machine Quick Detail: Radius: R8M Strand Number :5 Strands Rigid With Self-adapting Dummy Bar Head With ISO Certification We Can Produce High Quality Continuous Casting Machines From 1 To 8 Strands With The Lowest Equipment Manufacturing Cost.We Can Design, Manufacture The Up-to-date Billet Continuous Casting Machine In Accordance With The User's Steelmaking Capacity, Billet Size, Steel Grades And The User's Field Conditions. 1. Basic Standby Technical Parameters: - - - - Steel Billet Casting Machine Radius | 8m | Strand Quantity | 5 Strands | Ladle Support Type | Ladle Turret | Ladle Turret | Straight Arm Type | Tundish Car | High-low Track Drive, Cross Sliding Function | Casting Method | Metering Nozzle, Open Casting,casting Powder | Secondary Cooling | Gas And Water Cooling ,2 Adjusting Circuit Per Strand | Withdrawal Straightening Machine | Totally 5 Roller, Progressive Straightening | Roll Table | Chain Group Centralized Drive | Dummy Bar | Rigid, With Self-adapting Dummy Bar Head | Billet Cutting | Auto Flame Cutting Machine | Billet Conveying | Group Centralized Live Roller Table | Cooling Bank Type | Sliding Way,shift Steel Machine | - - - - 2. Technical Process Description And Capacity Of Steel Billet CCM Induction Furnace: - - - - Nominal Capacity | 60T | Tap-to-tap Cycle | 45min | Furnace Quantity | 1set | - - - - Production Capacity - - - - Working Days | 330 Days/year | Average Number Of Daily Furnace | 24/day | Production Capacity | 600,000800,000t/year | - - - - 3. Casting Speed, Productivity And Strand Quantity R8m Radius Casting Machine Can Cast Steel Groups Of
