Rotary Drilling Rigs TR220 Technical Specifications - Product


Place of Origin : Beijing,China
Delivery Time : ON STOCK

Product Description


RotaryDrilling Rigs TR220 Technical Specifications
Designed and manufactured to ISO9001 standards and CE certificate. Hydraulic piling rig 220 is composed of a Caterpillar base unit on crawlers and of a drilling application module for:-
# Drilling with telescopic friction or interlocking Kelly bars standard supply
# Optional casing oscillator application - optional

Rotary Drilling Rig TYPE TR220

- - - -
TR220-Technicalspecifications |
| EuroStandards | U.S.Standards |
Maxdrillingdepth |

Physical Specification

Other Specification :  RotaryDrilling Rigs TR220 Technical Specifications Designed And Manufactured To ISO9001 Standards And CE Certificate. Hydraulic Piling Rig 220 Is Composed Of A Caterpillar Base Unit On Crawlers And Of A Drilling Application Module For:- # Drilling With Telescopic Friction Or Interlocking Kelly Bars Standard Supply # Optional Casing Oscillator Application - Optional Rotary Drilling Rig TYPE TR220 - - - - TR220-Technicalspecifications | | EuroStandards | U.S.Standards | Maxdrillingdepth | 60-66m | 197-217ft | Maxholediameter | 2000mm | 79in | Enginemodel | CATC-9 | CATC-9 | Ratedpower | 213KW | 286HP | Maxtorque | 220kN.m | 162206lb-ft | Rotatingspeed | 627rpm | 627rpm | Maxcrowdforceofcylinder | 180kN | 40464lbf | Maxextractionforceofcylinder | 200kN | 44960lbf | Maxstrokeofcrowdcylinder | 5300mm | 209in | Maxpullingforceofmainwinch | 200kN | 44960lbf | Maxpullingspeedofmainwinch | 78m/min | 256ft/min | Wirelineofmainwinch | 28mm | 1.1in | Maxpullingforceofauxiliarywinch | 110kN | 24728lbf | Undercarriage | CAT330D | CAT330D | Trackshoewidth | 800mm | 32in | Widthofcrawler | 3000-4300mm | 118-170in | Wholemachineweight | 65T | 65T | - - - -
