Seamless GR2 Titanium Pipe - Product

Other Specification :  GR2 Astm B862 Titanium Welded Pipe For Heat 1.Standards: ASTM B/ASME SB 338, 862 2.Gr.1, Gr.2, Gr.7, Gr.12 3.OD: 5-160mm; WT: 0.5-10mm; Length: Less Than 15 Meters Features: 1) Standards: ASTM B/ASME SB 338, 862 2) Gr.1, Gr.2, Gr.7, Gr.12 3)Seamless And Welded Pipe 4) OD: 5-160mm; WT: 0.5-10mm; Length: Less Than 15 Meters 5)Eddy Current Testing,Ultrasonic 6) We Are Checked By A&V,B&V,SGS 7)Usedarea:Heatexchangersandcondensers Allkindsofcorrosivefluidtransmissionpipelinesystem Titaniumbicycletubes,automobileexhaustpipe Offshoreaquaculture 8)OEMandcustomersdesignsareacceptable 9)Finalproducttest: Ultrasonictest,Eddycurrenttest,Hydraulictest,Bendtest,Flaringtestandsoon. Specifications: - - - - Grade | Condition | Manufacturing Method | OD | Wall Thickness | Long | Standard | Gr1 Gr2 | Annealed | Cold Rolling Seamless | 10-15MM | 0.5-4.5 MM | 500-4000MM | ASTM B337 ASTM B338 | 15-20MM | 0.6-2.5 MM | 500-9000MM | 20-30MM | 0.6-2.5 MM | 30-40MM | 1.0-2.5 MM | 40-50MM | 1.5-3.0 MM | 50-60MM | 1.5-3.5 MM | 60-80MM | 2.0-4.5 MM | Welded | 16MM | 0.5-1.0 MM | 500-15000MM | 19MM | 0.5-1.25MM | 25 27MM | 0.5-1.5 MM | 500-6000MM | 31 32 33MM | 0.8-2.0 MM | 38MM | 1.5-2.5 MM | 500-4000MM | 50MM | 2.0-2.5 MM | 63MM | 2.0-2.5 MM | Welded ------- Rolling | 6-10MM | 0.5-1.25 MM | 500-8000MM | 10-15MM | 0.5-1.5 MM | 15-20MM | 0.5-2.0MM | 500-5000MM | 20-25MM | 0.5-2.0 MM | 25-30MM | 0.5-2.0MM | - - - - - - - - Titanium Welded Pipe For Heat Exchanger Equipments Titanium Welded Pipe
