JH4540 engraver machine - Product
Place of Origin : Hefei,China
Delivery Time : Normally Within 5-7 Working Days For Standard Mach
Payment Terms : T/T 100% Before Delivery
Product Description
Gold Mini CNC Router JH4540 (All)
Description
Use iron casting tempering technology for making machine body, great rigidity, moving stable and few vibration
Imported rolling ball screw for X.Y.Z axis, sliding warning devices to make sure no clearance and high precision
High quality driver motors, spindle motors,cables, inverter etc.
Professional CNC control system, can compatible wit many kinds CAM software, such as Type3, ARTCAM, UG,PRO-E,MASTERCAM, etc
Basic Information
Brand : GOLD
Model : JH4540
Material : Metal
Physical Specification
Other Specification : Parameter Of JH4540
Model JH 4540(moving Table)
Working Area 450*400*70mm
Table Size 450*400mm
Spindle Motor 1500W Inverter-driven Spindle Motor Cooled By Water
X, Y, Z Traveling Positioning Accuracy 0.01 Mm
X, Y, Z Repositioning Positioning Accuracy 0.01 Mm
Table Surface Cast-iron
Frame Metal Casting Body
X, Y Z Structure Imported Rolling Ball Screws For X ,y And Z Axis , Sliding Warning Devices To Make Sure No Clearance And High Precision
Max Motion Speed 8000mm/min
Max Engraving Speed 5000mm/min
Rotation Speed Of Spindle 6000-24000rpm
Drive Motors Step Motor
Max Consume Power ≤2KW
Working Voltage One Phase AC 220V/50-60HZ
Engraving Tool 3.175mm/6mm (Standard Configuration Is 10 Pc , With Any Special Requirement ,please Inform Us)
Operating System NC-Studio (work With Computer ). DSP Is Optional Which Is Able To Work Without Computer
Format Dictate HPGL Or G-code
X, Y Resolution 0.01mm
Software Compatibility Compatible With Popular CAD/CAM Software: Type3/Artcam
Package Size 850x960x1400mm (Non-wooden Package)
Running Circumstance Temperature : 0°-45°C
Relative Humidity :30%-75%
