H.264 Mini High Speed Infrared Dome IP Camera CC268A - Product
Place of Origin : Shenzhen,China
Product Description
1. Compatible for Axxon,NUUO,Ivideon,VLC media player,Milestone,Avigilon and other client software;
2. High Speed PTZ IP Camera;
3. 1/4 inch, Interline Transfer CCD;
4. Optic 10x,Digital 10x Zoom;
5. Support ONVIF;
6. Auto / Day / Night (ICR);
7. 30pcs of 5Ф infrared lights, visual distance over 30m at night;
8. Samsung mechanism;
9. POE optional.
Physical Specification
Other Specification : Network And Video Spec:
Video Compression:H.264 Main Profile @Level 3
Processor:Hi3507
Video Resolution:PAL:960*576,704*576(4CIF),704*288(2CIF),352*288(CIF),176*144(QCIF)
NTSC:960*480,704*480(4CIF),704*240(2CIF),352*240(CIF),176*120(QCIF)
Video Frame Rate:PAL: 1-25frames/second
NTSC:1-30frames/second
Video Compression Bit Rate:16-8000kbps
Supported Protocols:TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPsec, UPNP,RTP,RTSP,IPV4
Streaming Format:Video Streaming Or Audio &Video Composite Streaming
Audio Compression:G.711
Audio Input:1 Channel
Audio Output:1 Channel
Title OSD:Support
Alarm Input:1channel,Optional
Alarm Output:1 Channel,Optional
E-mail Alarm:Support
Speed Dome Spec:
Mechanism:Samsung,10*10x
Pan / Tilt Range:Pan: 360°(Endless), Tilt: 180°(Auto Flip),95°(Normal)
Pan / Tilt Speed:Preset: 360°/sec,Swing: 1~180°/sec
Manual: 0.05~360°/sec(Proportional To Zoom)
Preset:127 Preset ( Label, Camera Image Setting )
Pattern:4 Patterns, 1200 Commands ( About 5 Minutes)/Pattern
Swing:8 Swing
Group:8 Groups ( 20 Actions Entities Per Group )
Other Functions:Auto Flip, Auto Parking, Power Up Action Etc
Communication:RS-485
Protocol:Pelco-D, Pelco-P Selectable
Privacy Zone:4 Zones
Alarm Input:4 Inputs
OSD:Menu / PTZ Information Etc
Camera Spec:
CCD:1/4" Interline Transfer CCD
Max. Pixels:811(H)×508(V)410K NTSC
795(H)×596(V) 470K PAL
Effective Pixels:768(H)×494(V) 380K NTSC
752(H)×582(V) 440K PAL
Horizontal Res.:500 TVL(Color),570 TVL(B/W)
S/N Ratio:50dB(AGC Off)
Zoom:10X Optical Zoom, 10X Digital Zoom
Focal Length:F1.8, F=3.8~38mm
Min. Illumination:0.7Lux (Color), 0.02Lux (B/W), 50 IRE
Day & Night:Auto / Day / Night (ICR)
Focus:Auto / Manual / Semi-Auo
Iris:Auto / Manual
Shutter Speed:128X~1/120000 Sec
AGC:Normal / High / Off
White Balance:Auto / Manual / (Red, Blue Gain Adjustable)
