SUNTRONIX AC FAN 120x120x25 mm - Product
Place of Origin : Shenzhen,China
Delivery Time : 25-30 Work Day
Product Description
120x120x25 mm 110V, 220V / 240V Exhaust AC Axial Fans, water proof IP44 Fan SJ1225HA2
# 120x120x25mm
# AC FAN , Cooling Fan
# High speed (low speed is available)
# Aluminum Frame
# 7 blades
# 110V AC or 220V AC
# Ball bearing or Sleeve bearing
# Terminal connection or lead wire
# Industrial Fan,AC Axial Fan,Cooling Fan,Exhaust Fan
# # Frame Type: Aluminum painted& Plastic UL94V-0;
# Impeller:Thermoplastic UL94V-0 P.B.T.
# Bearing:Ball Bearing& Sleeve Bearing
#
Physical Specification
Other Specification : 120x120x25 Mm 110V, 220V / 240V Exhaust AC Axial Fans, Water Proof IP44 Fan SJ1225HA2
# 120x120x25mm
# AC FAN , Cooling Fan
# High Speed (low Speed Is Available)
# Aluminum Frame
# 7 Blades
# 110V AC Or 220V AC
# Ball Bearing Or Sleeve Bearing
# Terminal Connection Or Lead Wire
# Industrial Fan,AC Axial Fan,Cooling Fan,Exhaust Fan
# # Frame Type: Aluminum Painted& Plastic UL94V-0;
# Impeller:Thermoplastic UL94V-0 P.B.T.
# Bearing:Ball Bearing& Sleeve Bearing
# Ingress Of Protection:IP44
Detail More:
# Voltage :110V, 220V, 230V
# Insulation Resistance:Min.100M Ohm At 500 VDC Between Terminal(wire)(+)and Frame
# Dielectric Withstand:1500VAC For 1 Second Between Terminal(wire)(+)and Frame
# Opetation Temperature:-2085(Ordinary Humidity
# Storage Temperature:-30140(Ordinary Humidity)
# Life Expectancy:60, 000Hours At 20-Ball Bearing
30, 000Hours At 20-Sleeve Bearing
# Safety:UL, CUL, TUV, CE, CCC, ROHS, C-TICK Approved
Applications:
# # San Jus Fan Products Are Utilized By All Type Of Machines Which Required Heat Reduction Systems,
# Such As UPS Systems; Telecommunication Equipments; Ventilating Systems; LED Digital Signage; Disports/exercise Equipments; Medical Instruments.
Competitive Advantage:
*Qualified, Cost Effective And Easily Operated
*Small In Shape, Have Compact Structure
*UL, CE, Rohs, CUL, CCC
* Competitive Pricing
* Keep Investing And Developing In New Products
* The Most Advanced Testing And Measuring Equipment
* On-Time Delivery
#
