5V / 120km / Multi - mode fiber GBIC Optical Transceiver - Product

Other Specification : Features: 850/1310/1550nm FP Or DFB LD Transmission SC Interface , Power Supply +5V , With Hot-pluggable LC Interface Transmission Distance:120km Max Single Mode Or Multi-mode Fiber Optional Compliant With IEEE802.3Z 1000BASE-LX/SX/ZX Specification Compliant With IEEE-802.3 And ANSI Specification Compliant With Telcordia(Bellcore)GR-468-CORE Specification Compliant With ITU-T G.957/958 Specification Applications: ATM, SDH, SONT, PDH Data Communication Network Telecom System High Speed Transmission System Ordering Information: - - - - Part No | Data Rate | Tx | S | Rx | Pout | Reach | Top | Others | Application | OP-MG485S1M4-0.55 | 1.25Gbps | 850nm | <-17dBm | PIN | -9.5~-4dBm | 0.55km | 0~70 | VCSEL;5V&3.3V | Ethernet, Fiber Channel, SDH | OP-MG413S1S4-10 | 1.25Gbps | 1310nm | <-23dBm | PIN | -9.5~-3dBm | 10km | 0~70 | FP;5V&3.3V | Ethernet, Fiber Channel, SDH | OP-MG413S1S4-40 | 1.25Gbps | 1310nm | <-24dBm | PIN | -2~2dBm | 40km | 0~70 | DFB;5V&3.3V | Ethernet, Fiber Channel, SDH | OP-MG415S1S4-40 | 1.25Gbps | 1550nm | <-23dBm | PIN | -4~0dBm | 40km | 0~70 | DFB;5V&3.3V | Ethernet, Fiber Channel, SDH | OP-MG415S1S4-80 | 1.25Gbps | 1550nm | <-24dBm | PIN | 0~5dBm | 80km | 0~70 | DFB;5V&3.3V | Ethernet, Fiber Channel, SDH | OP-MG415S1S4-120 | 1.25Gbps | 1550nm | <-30dBm | APD | 0~5dBm | 120km | 0~70 | DFB;5V&3.3V | Ethernet, Fiber Channel, SDH | OP-MDG6XLXD-70 | 1.25Gbps | CWDM | <-24dBm | PIN | -2~5dBm | 70km | 0~70 | DFB;5V&3.3V | CWDM | - - - -
