Funduino Duemilanove Development Board - Product

Other Specification :  Funduino Duemilanove Development Board 2009 For Arduino Based On ATmega328 Funduino Duemilanove 2009 Development Board Compatible ARDUINO Description: The Duemilanove Board Arduino Is A Microcontroller Board Based On The ATmega328. It Has 14 Digital Input/output Pins (of Which 6 Can Be Used As PWM Outputs), 6 Analog Inputs, A 16 MHz Crystal Oscillator, A USB Connection, A Power Jack, An ICSP Header, And A Reset Button. It Contains Everything Needed To Support The Microcontroller; Simply Connect It To A Computer With A USB Cable Or Power It With A AC-to-DC Adapter Or Battery To Get Started. Specifications: - - - - Microcontroller | ATmega328p | Operating Voltage | 5V | Input Voltage (recommended) | 6-11V | Digital I/O Pins | 14 (of Which 6 Provide PWM Output) | Analog Input Pins | 6 | DC Current Per I/O Pin | 40 MA | DC Current For 3.3V Pin | 300 MA | Flash Memory | 32 KB Of Which 2KB Used By Bootloader | SRAM | 2 KB | EEPROM | 1 KB | Clock Speed | 16 MHz | - - - - Test ProTest Procedure /* The Circuit: * LCD RS Pin To Digital Pin 8 * LCD Enable Pin To Digital Pin 9 * LCD D4 Pin To Digital Pin 4 * LCD D5 Pin To Digital Pin 5 * LCD D6 Pin To Digital Pin 6 * LCD D7 Pin To Digital Pin 7 * LCD BL Pin To Digital Pin 10 * KEY Pin To Analogl Pin 0 */ #include LiquidCrystal Lcd(8, 13, 9, 4, 5, 6, 7); Char Msgs[5][16] = {"Right Key OK ", "Up Key OK ", "Down Key OK ", "Left Key OK ", "Select Key OK" }; Int Adc_key_val[5] ={50, 200, 400, 600, 800 }; Int NUM_KEYS = 5; Int Adc_key_in; Int Key=-1; Int Oldkey=-1; Void Setup() { Lcd.clear(); Lcd.begin(16, 2); Lcd.setCursor(0,0); Lcd.print("ADC Key Testing"); } Void Loop() { Adc_key_in = AnalogRead(0); // Read The V
