Digital Electronic Tensile Testing Machine (Double columns) - Product

^{MINIMUM QUANTITY^1UNIT}

^{WARRANTY^1YEAR}

Place of Origin : Beijing,China
Delivery Time : 35days
Payment Terms : T/T,L/C

Product Description

WDS digital tensile testing machines are suitable for tensile and all other special load test for non metal material. For example, plastic tensile test, rubber tensile test, thread tensile test, wood tensile test, alloy tensile test, PVC, spring, electrical wire and cable, composite, profiled bar, waterproof roll, etc.

Basic Information

Brand : LARYEE
Model : WDS-0.5, 1, 2, 5, 10, 20
Expiry/Validation Period : 1YEAR

Physical Specification

Other Specification : Feacture: *High Accuracy Load Cell, Encoder And Optional Extensometer To Test The Force, Displacement And Extension. Reading Resolution Can Be 1/300000 Of Full Range. *Speed Servo Control From 0.01mm/min To 500mm/min By Servo Motor. *Easy To Install Many Kinds Of Test Grips And Accessories To Do Many Kind Of Test *Test Result Real Time And Peak Value Indicating. Force-Displacement And Force- Extension Curve Showing Option Function. *Data Save And Test Result Printing By Mini-printer. *Two Kind Of User Administrate System For Common Operator And System Administrator *Option Ethernet Socket To Connect To PC Or Laptop. Adding Professional Software, It Can Be Set A Computer Control 3 Close-loop Control Testing Machine By Load, Displacement And Extension. Model WDS-05 WDS-1 WDS-2 WDS-5 WDS-10 WDS-20 Range Of Testing Force (kN) 0.01-0.5 0.02-1 0.04-2 0.10-5 0.20-10 0.40-20 Accuracy Of Force ± 1% Of Indicated Value (± 0.5% As Special Order) Resolution Of Force 0.001 As Test Value Resolution Of Crosshead Displacement Measurement 0.01 Mm Displacement Accuracy ± 1% Speed Range Of Crosshead 0.01 Mm/min---500 Mm/min, Servo Control Speed Accuracy ± 1% CrossheadMove Range 0-1050mm Effective Testing Space 900mm Deformation Measurement ± 1% As Optional Part Connect To PC By Interface And Ethernet Cable As Optional Parts. Drive Type Servo Motor With Ball Screw Driver Power Supply 220V, Single Phase 50/60Hz Machine Type Double Columns Overall Dimension Of Host Machine (mm) Double: 740× 500× 1680 740× 500× 1680 Weight (kg) Single 300, Double 580
