Coating Thickness Gauge TG8830F - Product
Place of Origin : Haidian,China
Product Description
TG8830F portable coating thickness gauge is using the magnetism measuring thickness method .It can measure the thickness of the magnetism metal substrate (such as steel, iron, alloy and rigid magnetism steel and etc), non-magnetism cover layer (such as aluminum, chrome, copper, enamel, rubber, oil paint and etc) .This instrument has small error of measure, excellent performance and good stability, easy operation and other characteristics, is a necessary measure instrument to control and guarant
Physical Specification
Other Specification : TG8830F Portable Coating Thickness Gauge Is Using The Magnetism Measuring Thickness Method .It Can Measure The Thickness Of The Magnetism Metal Substrate (such As Steel, Iron, Alloy And Rigid Magnetism Steel And Etc), Non-magnetism Cover Layer (such As Aluminum, Chrome, Copper, Enamel, Rubber, Oil Paint And Etc) .This Instrument Has Small Error Of Measure, Excellent Performance And Good Stability, Easy Operation And Other Characteristics, Is A Necessary Measure Instrument To Control And Guarantee The Product Quality, Can Be Widely Applied To Manufacturing, Metal Processing Industry, Chemical Industry, Merchandise Test Fields.
Features
# Precise Measurements (2%+1)/(1%+1)
# Quick Measuring Response And Rapid Measuring Speed
# Design Of Two Independent Parts , Better Applicability, Stable Measurement Results
# Strong Data Processing And Analysis :5 Types Of Statistic Value And Histogram
Technical Specification
- - - -
Measuring Range | F1:0~1250m, |
Measuring Accuracy | 1 Point Calibration : (2%+1)2 Point Calibration : (1%+1) |
Calibration | 1 Point Calibration /2 Point Calibration /basic Calibration |
Display Resolution | 0.1um (0~99.9um) / 1um (Over 100um) |
Weight | 250g(including Battery Package ) |
Operation Environment | Temperature: 0~50 Humidity: 20%RH90%RH |
Operation Mode | Direct Testing Mode And Block Statistics Mode |
Measuring Mode | Continuous/single |
Shutdown Mode | Manual/automatic |
Operation Alarm | Ring Music To Alarm Mistake |
Signal Dealing |
Threshold | Limits Setting And Automatically Alarm Measured Values Out Of Limit |
Data Analysis | Analyzing A Batch Of Measuring Values Via Histogram |
Statistic Function | Mean/ Standard Deviation / Number Of Measurements/ Maximum/ Minimum |
Data Mero
