2400dpi Laser CTP Machine, Platemaking Prepress Machines - Product

Other Specification :  1. Name: CTCP 32 Channels Platemaking Prepress Machine 2. Application: Prepress Printing Equipment 3. Feature: Ultrahigh Frequency MOS Pipe And High Speed Operational Amplifier 2400dpi Laser CTP Machine, Platemaking Prepress Machines Description: DOIE UV-CTP 32 Channels Uses The Most Advanced And Stable Guide Rail Technology, Using Automatic Loading Way And 405nm Laser Diode, Digital Process Workflow, High Precision Dot, Low Cost UV(CTcP) Plates, Reducing The Cost. DOIE UV-CTP Uses Special Laser Diode And External Drum Design, To Ensure The Biggest Energy Transfer Efficiency And Exposure Precision. We Use Reliable Control Circuity System.By Using Control Method Of Negative Feedback, The Circuitry Achieve Constant-current Control, DA Output Power Adjust Continuously, LD Output Follow Control Signal, Which Output Pulse By Using On-off Mode, Therefore The Standby Power Is Low. Also With Ultrahigh Frequency MOS Pipe And High Speed Operational Amplifier Made The Voltage Pulse Rise And Fall Time On The LD Shortest. Specifications: - - - - Model | X-0322U | Light Channels | 32 | Output Speed(P/h) | 17 | P Size:1030mm800mm | 29 | P Size:510mm400mm | Light Source | 405 Nm Laser Diode | Output Resolution (dpi) | 2400 | Dot Reproduction | 1%99% | Register Accuracy (mm) | 0.01 | Plate Size (mm) | Max. 1160940Min. 450320 | Suitable Plates | Various UV-CTP(CTcP) Plates | Plate Thickness (mm) | 0.15~0.30 | Plate Loading And Unloading | Loading:Automation(Standard Set) Unloading:Automation Vacuum Fixation | Plate Position Accuracy (mm) | 0.2 | Plate Balance | Automatic Balance | Data Interface | USB,1000Mbit/s | Ambient | Temperature 253 Humidity 20~80%(Non-con
