Mono Crystalline Silicon Solar Panels (GCC5W-240W) - Product

^{MINIMUM QUANTITY^2PC}

^{WARRANTY^3YEAR}

Place of Origin : Shenzhen,China
Delivery Terms : FOB
Payment Terms : T/T

Product Description

This is part of our standard solar panel specification for you reference, If you don't find the specification you needed. Pls feel free to contact me. We will design it for you!
Our solar panel power range: 2W~240W

Basic Information

Brand : Goland Century
Material : Mono Silicon

Physical Specification

Other Specification : Wp(W) Vmp(V) Imp(A) Voc(V) Isc(A) L*W*H(mm) Cell(mm) Weight(Kg) 5 16.8 0.30 21.0 0.38 254*294*23 125*125 0.8 6 16.8 0.36 21.4 0.40 254*294*23 125*125 0.8 8 16.8 0.48 21.4 0.54 396*289*23 125*125 1.4 10 17.0 0.59 21.5 0.68 396*289*23 125*125 1.4 12 17.2 0.70 21.6 0.80 396*289*23 125*125 1.4 15 17.2 0.88 21.6 1.06 440*294*23 125*125 2.2 18 17.2 1.05 21.6 1.17 639*294*23 125*125 2.4 20 17.2 1.17 21.6 1.30 639*294*23 125*125 2.4 24 17.4 1.38 21.8 1.59 570*414*23 125*125 2.5 30 17.2 1.75 21.6 1.96 645*545*23 125*125 5.2 36 17.2 2.10 21.6 2.34 645*545*23 125*125 5.2 38 17.4 2.19 21.8 2.52 645*545*23 125*125 5.2 40 17.6 2.28 21.8 2.67 645*545*23 125*125 5.2 42 17.6 2.39 21.8 2.68 645*545*23 125*125 5.2 50 17.6 2.85 21.6 2.98 835*540*28 125*125 5.5 60 17.2 3.49 21.6 3.90 1210*540*28 125*125 8.2 65 17.2 3.78 21.6 4.35 1210*540*28 125*125 8.2 75 17.2 4.36 21.6 4.87 1210*540*28 125*125 8.2 80 17.6 4.55 21.8 5.23 1210*540*28 125*125 8.2 85 17.6 4.83 21.8 5.18 1210*540*28 125*125 8.2 100 33.5 2.99 41.5 3.75 1250*808*35 125*125 11.8 110 33.5 3.29 41.5 3.78 1250*808*35 125*125 11.8 120 33.8 3.35 41.5 4.26 1250*808*35 125*125 11.8 130 33.8 3.85 41.5 4.43 1250*808*35 125*125 11.8 150 34.4 4.37 43.0 4.86 1580*808*35 125*125 14.5 160 34.4 4.66 43.0 5.00 1580*808*35 125*125 14.5 165 35.87 4.60 43.0 4.90 1580*808*35 125*125 14.5 170 36.1 4.71 43.3 5.00 1580*808*35 125*125 14.5 175 36.45 4.81 43.7 5.10 1580*808*35 125*125 14.5 180 36.73 4.91 44.3 5.20 1580*808*35 125*125 14.5 200 44.8 4.47 50.3 5.20 1702*945*45 125*125 19.0 240 36.8 6.53 44.3 7.5 1620*1200*45 125*125 23
