300mm - 1200mm Metal U Beam Assembly Line , Automated Assembly Machine - Product


Place of Origin : Wuxi,China
Delivery Time : 45 Working Days After Down Payment

Product Description



300mm - 1200mm Metal U Beam Assembly Line , Automated Assembly Machine



Description:



This machine is mainly used for the welding of cover plate of box beam and inner
side welding seam of reinforcing plate inside box beam. It consists of base, column,
lifting arm, welding gun moving carriage, welding gun cross adjusting unit,
wire reel and guiding wire unit, and arc striking unit.





Specifications:



a. Structure principle

This is the special equipemnt for bo

Physical Specification

Other Specification :  300mm - 1200mm Metal U Beam Assembly Line , Automated Assembly Machine Description: This Machine Is Mainly Used For The Welding Of Cover Plate Of Box Beam And Inner Side Welding Seam Of Reinforcing Plate Inside Box Beam. It Consists Of Base, Column, Lifting Arm, Welding Gun Moving Carriage, Welding Gun Cross Adjusting Unit, Wire Reel And Guiding Wire Unit, And Arc Striking Unit. Specifications: A. Structure Principle This Is The Special Equipemnt For Bottom Plate, Web Plate And Baffle Plate Of Box Beam. It Is Composed Of Main Machine, Roller Conveyor, Centering Device, Positioning Device, Hydraulic System And Electric Control Box. Main Machine Is Composed Of Moving Boom, Column, Upper Cross Boom. Upper Platform, Upper Press Part, Side Press Part. The Two Moving Boom Have One Motor Reducer For Each, Driving The Four Moving Wheel Working, Which Form Double Driving System And Make Sure Working Stable. There Have Guide Rail On The Column And Upper Cross Boom, Which Make Moving For Side Press Part And Upper Press Part. There Have Lifting Oil Cylinder On The Top Of Vertical Boom And Driving The Elevating Moving Of Side Press Part. On Two End Of Upper Boom There Have Moving Oil Cylinder And Driving Horizontal Moving Of Upper Press Part. The Upper Press Part Is Install On The Guide Rail Of Upper Cross Boom, It Can Make Horizontal Move On Upper Cross Boom. The Upper Press Part Is Composed Of Upper Press Oil Cylinder, Press Head, Slide Base, C Shape Frame. It Good Advantage Is The Press Force Dont Reach To The Roller, It Is Bearing By Press Head And C Shape Frame, Which Avoid There Have Heavy Force Damage The Roller. The Side Press Part Install On The Vertical Guide Rail, It Can Make Elevating Moving Along To The Column. The Side Press Part Is Composed Of Side Press Oil Cylinder, Press Head, Slide Base. The Back
