MicroStac connector - Product
Place of Origin : Shenzhen,China
Product Description
Pitch: 0.8mm
Pins: 6, 9, 10, 12, 14, 50, 54
Termination: SMT
Standard: n.a.
Datarate: n.a.
The MicroStac connector series is a hermaphroditic design. The connector and the counter connector are identical, and the typical subdivisions of male- and female-multipoint connectors are omitted. Nevertheless, ERNI discovered a way to implement two contact points (similar to double female contact). The design calls for fast, fully automatic SMT assembly. We use the tilt-proof contact principle by
Basic Information
Brand : ERNI
Physical Specification
Other Specification : Pitch: 0.8mm
Pins: 6, 9, 10, 12, 14, 50, 54
Termination: SMT
Standard: N.a.
Datarate: N.a.
The MicroStac Connector Series Is A Hermaphroditic Design. The Connector And The Counter Connector Are Identical, And The Typical Subdivisions Of Male- And Female-multipoint Connectors Are Omitted. Nevertheless, ERNI Discovered A Way To Implement Two Contact Points (similar To Double Female Contact). The Design Calls For Fast, Fully Automatic SMT Assembly. We Use The Tilt-proof Contact Principle By Way Of Dual-side Positioning Of The Contact On The Circuit Board. In Addition, We Use The Very Low Weight, As Well As The Insulator Body-integrated Grip Surface, For The Vacuum Pipette And The Tape-and-reel Packaging.
