Digital Processor Loudspeaker Management System - Product

Other Specification :  Digital Processor Loudspeaker Management System Quick Detail: - - - - Name | 2 In 6 Out Digital Speaker Management, Processor MSM26 | Type | 2 In 6 Out | Certificate | CE | MOQ | 2PC | - - - - Specifications: - - - - Input | 2 | Input Impendance | 10K Ohm, Electronic Balance Input | Max. Input Level | 50dB (30Hz-20KHz) | Output | 6 | Output Impendance | 50ohm, Electronic Balance Input | Max. Output Level | Vpp=4V Balance, Vpp=7.6V Unbalance | Sample Rates | 48kHz | Bit Depth | 24 Bit | Frequency Response | 20Hz To 20kHz 3dB ( Filter Disabled) | THD | 0.005% (+10dBu, 20Hz To 20kHz, 30kHz Bandwidth) | Dynamic Range | 112dB ( A-weighted, 22kHz Bandwidth) 109dB ( Unweighted, 22kHz Bandwidth) | Gain | 12dB And Mute. 1dB Steps | Output Channel Source | Input A, Input B And UM | HP Filter Frequency | <10Hz ~16KHz | LP Filter Frequency | 35Hz ~22KHz | LP/HP Filter Types | 12, 18 & 24dB/oct Bessel And Butterworth 12, 18 & 24dB/oct Linkwltz Rlley | Limiter | Threshold -20~+15dB Attack Time 1~100ms Hold Time 0~100ms Decline Time 10~1000ms | EQ Frequency | 10Hz To 25kHz, 1/36 Octave Steps | EQ Gain | -15 To +15, 0.1dB Steps | EQ Width | 0.1 To 5.0 Octaves Bandwidth, 1/36 Octave Steps | Audio Inputs | 3 Pin Female XLR | Audio Outputs | 3 Pin Male XLR | Serial Comms | 9 Pin D Type | Network Comms | Neutrik EtherCon | Mains | Universal Switch-mode PSU. 85-250V AC | Mains Power | 50-60Hz | Power Consumption | 25W | Dimensions | 482x158x45mm ( LxWxD) | Weight /N.W. | 3.6kg ( Net) | - - - -
