Standard Portable Ablution Container - Dismountable, Sandwich Panel Panelized - Product

Other Specification : Standard Portable Ablution Container - Dismountable, Sandwich Panel Panelized Description: This Is Made From One Standardcontainer House. The Overall Size Ofthe House Is 2.4m*6m. Cabin Is Consisted Of Ready-made Floor Frame, Roof Frame, Wall Panels, Internal Partitions And Accessories. Plumbing Pipe And Sanitary Wares Are Provided. Outlests Are Pre-cut In Factory For Easy Site Installation. 2 Workers Can Assemble On Basic Unit Within 4 Hours (about 14.4 Square Meters). For This Building, It Needs2 Man.days. Its Convenient For Folding. 4 Units Packed To One 20 Feet Container During Delivery, So It Is Suitable For International Transportation. Specifications Of Each Unit: I.Dimension(mm)Weight(kg) L=6055mm, W=2435mm, H=2790mm II. Steel Frame: Galvanized Steel Frame With Marine Paint Finishes Load Bearing - Floor Load: Max. Load Capacity 2.0 KN/m (200 Kg/m) Capacity- Wind Load: 25 M/s (90 Km/h) III.Wall : 50 - 100mm Thick Sandwiched Panel IV.Insulation : 50-100mm Thick Rockwool Or Neopor EPS V. Door: 900 X 2100 Mm Alum. Frame Metal Door Or PVC Door VI. Windows: 800 X 1000 Mm Alum. Frame Or PVC Window Competitive Advantage: Knock-down Panel Wall Saves Transport And Storage Space Top And Bottom Are Pre-assembled In The Factory In Order To Minimize The On-site Work With Firm Structure, The Earthquakes And Typhoons Can Be Resisted With The Insulation Material Of Rock Wool And Noepor Polystyrene, Good Fireproof Performance Is Available. Modular Design, Be Linked On Unlimited Extension Easy To Be Repaired And Maintained For High Standardization. Life Time 30 Years.
